21
28
27
30
22
25
24
26
29
23
Item no. Part no. Part name Service part
21 9379908030 Total panel sub assy ♦
22 9379570015 Sirocco fan assy ♦
23 9379644006 Rubber (Vibration proof) ♦
24 9379572019 Casing B ♦
25 9379571012 Casing U ♦
26
9379047166 Fan motor assy (For 07 model) ♦
9379047159 Fan motor assy (For 09, 12, 14 model) ♦
27 9378450097 Hose sub assy ♦
28 9379914062 Drain pump sub assy ♦
29 9378593039 Float switch sub assy ♦
30 9379913003 Drain hose assy ♦
3-3. Slim duct type - (02-17) - 3. Indoor unit parts list
