21 Louver Assy
22 Motor Cover
25 Motor Case
26 Drain Cover Assy
24 Shaft Cover
23 Step Motor
2015.10.23
DECORATION PANEL
UTG-UKYA-W
9381693009
9381354009
27 Bezel 9381353002
9381356003
9381713004
9381357000
9900885007
Ref. Description
Part number
24
25
21
27
26
23
22
12
