INDOOR UNIT
AUXG18LRLB
AUXG24LRLB
42
Insulation Box Sub Assy
Pipe cover
2015.11.25 18
43 Wind Guide Board 9382125004
9378580121
41
Cabinet B
sub assy
Cabinet A L
9381787012
Top plate assy
Evaporator holder
Ref. Description
Part number
Evaporator Total Assy (18)
42 9378580114Evaporator Total Assy (24)
41
42
43
