Fujitsu AOYG18LBCB - Page 18

OUTDOOR UNIT
AOYG18LBCB
2018.01.09 17
12 Front panel assy 9322555021
11 Top panel assy 9322556066
14 Emblem 9319151007
13 Blow grille 9322149008
16 Cabinet right assy 9322552099
15 Switch cover assy 9322570024
Ref. Description Part number
17 Propeller fan 9322150004
16
15
13
11
17
12
14
