Fujitsu AOYG18LBCB - Parts (Indoor Unit)

PARTS
INDOOR UNIT
ABYG18LVTB
10
6
4
7
3
5
1
2
Hanger
bracket L
RFM
(control box
metal bracket)
Hanger
bracket R
3 Cosmetic panel R 9358535028
4 Cosmetic panel L 9358536025
1 Remote control 9379219037
2
Remote control holder 9305642045
6 Kit (grill sub assy) 9372676035
7 Air filter 9358567036
5 Top cover 9358534021
Ref. Description
Part number
2017.07.31
9 Panel sub assy 9359057239
8 Panel assy 9359076322
8
9
