INDOOR UNIT
ABYG18LVTB
Flap base assy
11
11 Flap (upper) F 9358538029
12 Kit (flap lower) 9372671023
13 Bushing 9357942001
14 Bushing C 9358553008
16 Louver link 9358556009
17 Louver shaft 9358557006
18 Louver link cover 9358558010
19 Motor base assy 9359067030
15 Step motor H 9900297015
20 Step motor V 9900362010
Ref. Description
Part number
2016.01.20
15
17
14
16
18
20
19
12
13
13
11
