INDOOR UNIT
ABYG18LVTB
Kit (flap base sub assy)
12
24 Louver 9358561027
25 Bushing B 9358554005
28 Motor rod 9358560013
23 Protect cover 9358564011
Support stay
26 Louver stopper 9358555002
27 Louver rod 9358559017
22 Flap base 9358537022
21
Kit (flap base sub assy) 9372670040
Ref. Description
Part number
2016.01.20
28
26
23
21
27
22
24
25
