Fujitsu AOYG18LBCB Service Manual

P1 P30P5P10P650
P60
W400 W401 W402 W102
W103
W104
W70
W100
W101
W(C)
V(S)
U(R)
CM
1 2 3 4 5 6 7
1 2 3 4 5 6 7
1 2 3
1 2 3 1 2 3
1 2 3 1 2 3 4
1 2 3 4
1 2 3 4 5
1 2 3 4 5
1 2 3
1 2 3
Green
Red Black White Yellow Brown Black Black Black Black Black Black Black Black Red Blue Orange Yellow White
Red White Black Green Red Black White Black White Blue Red
Compressor
18 type
Terminal
1 2 3 L N
To Indoor unit Power source
4-Way valve coil
Fan motor
FM
PMV
4WV
Thermistor ( Pipe mid. temp. ) Thermistor ( Outdoor temp. ) Thermistor ( Pipe temp. ) Thermistor ( Discharge temp. )
Expansion valve coil
Main PCB
OUTDOOR UNIT
AOYG18LBCB
2018.01.16
6

Fujitsu AOYG18LBCB Specifications

General

Type	Air conditioner outdoor unit
Ionizer	No
Multi-split	-
Product color	White
Gas hose diameter	12.7 mm
Hose length (max)	25 m
Hose length (min)	15 m
Remotely operated	Yes
Drain hose diameter	32 mm
Liquid hose diameter	6.35 mm
Refrigerating medium	R410A
Dehumidifying capacity	2 l/h
Air conditioner functions	Cooling, Dehumidifying, Heating
Cooling capacity in watts (nominal)	5200 W
Cooling energy efficiency (EER, W/W)	3.21
Heating energy efficiency (COP, W/W)	3.61
Operating temperature (cooling) (T-T)	-10 - 46 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
Seasonal efficiency rating (cooling) (SEER)	6.1
Seasonal efficiency rating (heating) (SCOP)	4.2
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	6000 W
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	4
AC input voltage	230 V
Current (cooling)	11.5 A
Current (heating)	13.5 A
AC input frequency	50 Hz
Design load (cooling)	298 kW
Energy efficiency class (cooling)	A++
Hourly energy consumption (cooling)	- kWh
Design load (heating) (Warmer heating season)	- kW
Design load (heating) (Average heating season)	1819 kW
Energy efficiency class (heating) (Warmer heating season)	A+
Outdoor unit depth	290 mm
Outdoor unit width	799 mm
Outdoor unit height	632 mm
Outdoor unit weight	36000 g
Outdoor units quantity	1
Outdoor unit noise level	50 dB
Cooling airflow (outdoor unit)	2380 m³/h
Indoor unit noise level (high speed)	- dB
