Fujitsu AOYG30KATA Service Manual

2. Dimensions
2-1. Indoor unit
¢ Model: AUXG24KRLB
Unit: mm
950
View A
342
796
293
200 to 205
10
39
950
950
620
768
420
Hanging bolt position
Hanging bolt position
Indoor unit
Drain hose
View B View C
A
B
C
Ceiling
200 to 205
200
342 45
40
140
256
Wire hole
237
40
40
163
Fresh air inlet (cut out)
100
83
100
83
352
109
163
90
4 × Ø3.2
hole
Ø95
80
80
2-1. Indoor unit - (01-8) - 2. Dimensions
