Fujitsu AOYG30LFT User Manual

OUTDOOR UNIT
2011.01.31 20
30
26
32
31
21
33
22
23
27
25
24
34
29
28
Ref.
21 Strainer Assy 9372524015
22 3-Way Valve Sub Assy 9377958013
23 3-Way Valve Assy 9377959010
24 Check Joint Assy 9372802038
25 Compressor 9810135001
26 Accumulator 9385005006
28 4-Way Valve 9900164010
29 Solenoid 9970055034
30 Pressure Switch 9900186012
31 Inlet Pipe (Cond) A Assy 9373461067
27 Accumulator Support Assy 9355351003
32 Outlet Pipe (Cond) A Assy 9374266104
33 Expansion Valve Assy 9370947144
34 Expansion Valve Coil 9970095030
-- Muffler 9372369050
Part numberDescription
