1-5. Compressor frequency limitation by outdoor temperature
¢ Models: AOYG18KBTB, AOYG22KBTB, and AOYG24KBTB
The minimum compressor frequency is limited by outdoor temperature as below.
• Cooling/Dry mode
F zone
38°C
E zone
19°C
D zone
10°C
C zone
B zone
A zone
0°C
-10°C
Model name Outdoor temperature zone
Limitation of compressor
frequency
AOYG18KBTB
A zone 30 rps
B zone 30 rps
C zone 22 rps
D zone 16 rps
E zone 1 rps
F zone 25 rps
AOYG22KBTB
A zone 33 rps
B zone 33 rps
C zone 31 rps
D zone 19 rps
E zone 1 rps
F zone 20 rps
AOYG24KBTB
A zone 31 rps
B zone 31 rps
C zone 29 rps
D zone 20 rps
E zone 1 rps
F zone 29 rps
1-5. Compressor frequency limitation by outdoor temperature - (04-9) - 1. Compressor frequency control
