20 Drain Pan Assy
2013.02.13 20
INDOOR UNIT
9378207011
20
12 Sensor Holder
13 Float Switch
16 Drain Pump Holder B
17 Pump Rubber
18 Drain Hose
19 Drain Port
9378329010
9900465018
11 Float Switch Sub Assy 9378593015
15 Pump Assy 9900464011
14 Drain Pump Sub Assy 9378592018
9375518011
9378426016
9378212015
9378213012
- Drain Hose
- Hose Band
9379665001
9379757010
Ref. Description Part number
15
13
12
11
19
18
14
17
16
