INDOOR UNIT
26 Turbo Fan Assy
28 Motor, DC Brushless
29 Rubber (Motor)
25 Cabinet C Sub Assy
2013.02.13 21
9378228016
27 Turbo Fan Washer 9378394018
9602716005
9378223011
9378570016
24 Cabinet B Sub Assy
23 Cabinet A Sub Assy
9378595019
9378594012
22 Top Plate Assy 9378395015
Ref. Description Part number
21 Evaporator Total Assy 9378580015
21
29
28
29
23
22
25
24
29
26
27
