INDOOR UNIT
CASSETTE
AUYG18LVLB
25
21
25 2 Stage Turbo Fan Assy 9375480011
24 Turbo Fan Washer 9375487010
22 Evaporator Total Assy 9375720070
23 Evaporator Holder 9375508012
26 Fan Motor 9602436019
21 Separate Wall 9375506018
Ref. Description Part number
27 Fan Motor Holder 9375552015
31 Float Switch 9900361037
32 Drain Port Sub Assy 9375718015
30 Rubber (Pump) 9378426016
28 Pump Assy 9900472030
29 Drain Pump Holder B 9375518011
Ref. Description Part number
442012.09.20
22
23
23
27
26
31
28
32
30
29
24
