INDOOR UNIT
2012.04.09 19
PARTS
12
13
14
15
11
10 Air Filter 9359739012
1 Kit (Base Sub Assy) 9371360010
11 Front Panel 9359734017
9 Intake Grille 9359738015
15 Badge 9359735175
5 Cover (Decoration) R 9359744016
6 Cover (Decoration) L 9359745013
12 Indicator PCB 9705891050
2 Panel Left Sub Assy 9360427014
3 Kit (Panel Right Assy) 9371361017
4 Top Cover 9359737018
7 Kit (Side Cover R) 9371364025
8 Kit (Side Cover L) 9371365022
14 Receiver Cover 9359714002
13 PCB Holder 9359736011
Ref. Description Part number
