C703
660/
450V
+
C702
660/
450V
+
C700
660/
450V
+
C701
660/
450V
+
R703
68K
<RS-5W>
R702
68K
<RS-5W>
R701
68K
<RS-5W>
R700
68K
<RS-5W>
W700
P I N
ORANGE
PURPLE
N I N
W701
W702
P OUT
YELLOW
W703
N OUT
BLUE
2012.02.29 18
OUTDOOR UNIT
CAPACITOR PCB
K07AP-0700HUE-P0
