INDOOR UNIT
CEILING
ABYG18LVTB
ABYG22LVTA
ABYG24LVTA
53
78
79
74
75
72
77
71
73
76
72 Sirocco Fan Assy 9385258006
77 Rubber 9385102002
73 Casing 9358543009
71 Motor Fixing Table 9358591000
76 Fan Motor Assy 9380636007
79 Motor Fixture 9358594001
78 Protector 9359282006
74 Casing Cover 9358544006
75 Barrier 9380671008
Ref. Description Part number
2012.04.24
