562014.06.19
44
46
43
45
41
42
41
44
--
Power Supply PCB
Parts numberDescriptionRef
Terminal 3P
Pipe Thermistor
9707398267
9306489045
9900498108
43 Reactor Assy 9707457018
42 Main PCB 9709245316
-- Room Thermistor 9900653019
46 Wired Remote Control 9318593013
45
Terminal 3P (Wired Remote)
9703345012
INDOOR UNIT
SLIM DUCT
ARYG18LLTB
