Page #13 background imageLoading...
Page #13 background image
Panel metal
Grille metal
11
Switch Holder
12
Longlife Filter
13
Filter Guide
14 Switch Spring
2015.10.26
DECORATION PANEL
UTG-UKYA-W
Intake grille assy
9378252028
9378253018
9381362004
9381688005
15 Switch 9381363001
Ref. Description
Part number
12
13
15
11
14
12
