Fujitsu AOYG54LBTA Service Manual

Name and shape Q’ty Description
Hexagon Screw
4
For mounting decoration panel
Washer
4
For mounting decoration panel
Tapping screw
2
For installing grille holding wire
Strap
4
For installing corner panel
DECORATION PANEL
UTG-UKYA-W
INDOOR UNIT
AUXG45LRLB
AUXG54LRLB
2015.10.26
ACCESSORIES
23
Name and shape Q’ty Name and shape Q’ty
Wired remote control
WIRED REMOTE CONTROL
1
Screw (M4 × 16mm)
For installing the remote
control
2
Cable tie
For remote control and
remote control cable
binding
1
Name and Shape Q’ty Description
Template
(Carton top)
1
For installing indoor unit
Washer
8
For installing indoor unit
Coupler heat insulation (Large)
1
For indoor side pipe joint (Gas pipe)
Coupler heat insulation (Small)
1
For indoor side pipe joint
(Liquid pipe)
Insulation
1
For installing drain pipe
Drain hose
1
For installing drain pipe
VP25 (O.D.32, I.D.25)
Hose Band
1
For installing drain hose
Drain hose heat insulation
1
For installing drain pipe
Cable tie (Large)
4
For fixing the connection pipe
Cable tie (Small)
2
For electrical wiring
