REPLACEMENT PARTS
09-22
PROCESS
Model : AOYR14/18LCC
7
6
7
The leads are connected with INVERTER ASSY
(TERMINAL COVER)
PCB side
COMP side
(BINDER)
B
D
D
E
E
0~10mm
COMP LEAD is passed TERMINAL COVER the under.
