OUTDOOR UNIT
Ref. Description
1 Top Panel Assy 9309230057
2 9314809040
3 Blow Grill 9308884015
4 Cabinet Right Assy 9309236011
5 Fan Ring 9308885012
6 Grip 9308880017
7 Switch Cover Assy 9309237025
8 Protective Net 9315319012
9 4-way Valve 9970036019
10 Pulse Motor Valve Assy 9314444012
9300089012
11 Condenser Assy 9314040023
12 Thermo Spring A 313728262708
13 Thermo Spring
14 Propeller Fan 9309909014
16 Motor Bracket 9308872012
17 Separater 9312032020
18 Base Assy 9308869081
19 3-way Valve Assy 9315159014
20 2-way Valve Assy 9313062019
21 Valve Bracket 9308870025
22 Cord Clamp 9307271014
23 Terminal 3P 9306489038
24 Inverter PCB Assy (14)
24 Inverter PCB Assy (18)
9707132014
25 TR PCB Assy 9705753013
26 ACTPM 9703457012
27 Fuse 0600086190
28 Fan Motor 9601815013
29 Compressor Assy 9314061011
30 Discharge Pipe Thermistor 9704219091
31 Heat Exchanger Thermistor 9704220028
32 Outdoor Thermistor 9703516092
33 Solenoid 9970055010
34
Expansion Valve Coil 9900057039
35
Choke coil 9703458019
---
Emblem 9315210012
---
Discharge Pipe Assy 9315283016
9707132021
36
Diode Bridge 0100122107
Part number
Cabinet Sub Assy
2010.09.03 16
