PARTS LIST
Ref. Description
41 Casing Assy 9313877040
42 Louver U Assy 9312243037
43 Spring EL 9312194001
47 Louver Z 9311996033
48 Spring F 9314143014
49 Diffuser U 9313856014
50 Diffuser Z 9313857011
51 Spring C 9314142017
59 Casing Cover F 9313839017
56 Casing Cover B 9313838010
57 Casing Cover L 9313887018
58 Casing Cover R 9313888015
44 Louver Cam 9312000012
45 Tension A 9312197002
46 Spring Holder 9311999010
52 Gear A 9309994003
61 Drain Hose Assy 9314147012
62 Drain Cap Assy 9304150008
60 Motor Cover 9313840013
22 Crossflow Fan Assy 9312004010
21 Bearing C Assy 9306628017
24 Control Box 9312005017
25 Controll Cover 9312006014
27 Receiver Case 9313842017
Part number
26 PCB Assy (14)
26 PCB Assy (18)
PCB Assy
= Controller PCB + Receiver PCB + Connector PCB
9707154016
28 Power Cord Assy 9900339029
29 Display Assy 9705808027
23 Fan Motor Assy 9601888017
53 Stepping Motor 9900467005
54 Stepping Motor (Pink) 9900527006
31 Gear Box Assy 9313880019
55 R and L Louver 9313858018
9707154023
2010.09.06 15
Indicator PCB 970580902430
INDOOR UNIT
Ref. Description
5 Open Panel Assy 9314405037
9 Air Filter 9313859015
4 Front Panel Total Assy 9313882150
6 Top Grill 9313848019
7 Top Cover 9313849023
10 Dust Box Assy 9313884024
8 Under Cover 9313850029
13 Evaporator Total Assy 9314964015
14 Joint Pipe Assy 9314111020
18 Sensor Case 9313843014
19 Sensor Cover 9313853013
Part number
15 Evaporator Holder R 9313833015
16 Evaporator Holder L 9313834012
17 Rear Bracket 9312416011
12 UV Unit 9313890018
11 Filter Guide 9313841010
1 Remote Control 9314157028
2 Remote Control Holder 9312947010
3 Bracket Panel 9312011018
