Fujitsu ARG30ALC User Manual

When you order parts, please make a photocopy of this page
OUTDOOR UNIT
and fill the number of the parts in the "Order" column.
Description
2
Fan Cover
9371187013
9371187013
9371187013
4
Emblem-Rear "FUJITSU"
9359836018
9359836018
9359836018
5
Cabinet-A, Painted
9359797043
9359797043
9359797043
7
Connector Cover (Panel, Top)
9358011010
9358011010
9358011010
9
Cabinet-B, Painted
9361323025
9361323025
9361323025
12
Base Assy, Painted
9359813019
9359812059
9359813019
13-1
Packed Valve (5/8)
9365096000
9365096000
9365096000
13-2
Packed Valve (3/8)
9360150004
9360150004
9360150004
15
Dryer Assy
9368111014
9368111014
9368111014
16
Condenser Assy
9365134009
9365438008
9365438008
17
U-Pipe (Y)
-----
9305523009
-----
18
Suction Pipe-A
9365095003
-----
9371590011
18
Suction Pipe
-----
9365409008
-----
20
Discharge Pipe
9365130001
9365419007
9365130001
21
Discharge Pipe-B
-----
9365412008
9371591018
21
Discharge Pipe-B
-----
-----
9365412008
26
Compressor Cover-A
9365154007
9365426005
9365154007
29
Separate Wall
9359805014
9359805014
9359805014
32
Control Box Metal
9365086001
9365086001
9365086001
34
Capacitor (Fan Motor)
9703306051
9703306051
9703306051
37
Running Capacitor
9703107122
9704436023
9703107122
38
Capacitor Clamp Metal
9364996011
9364996011
9364996011
39
Propeller Fan
9359837015
9359837015
9359837015
41
Fan Motor Assy-Out
9600832011
9600832011
9600832011
45-1
Motor Bracket
9369627002
9369627002
9369627002
45-2
Motor Bracket-B
9371439013
9371439013
9371439013
45-3
Motor Bracket-C
9369629006
9369629006
9369629006
45-4
Motor Bracket-D
9369630002
9369630002
9369630002
46
Compressor Assy
9371447018
9360509017
9371447018
47-1
Rubber (Discharge Pipe)
313194159807
-----
313194159807
51
Special Nut M5 (For Comp. )
9300301015
-----
9300301015
55
Special Nut M8 (For Comp. )
9355091008
9355091008
9355091008
64
Cabinet-Left, Painted
9359840046
9359840046
9359840046
69-3
Bolt, Hex. Socket
301210060360
301210060360
301210060360
79
Soft Starter
9704690012
9704690012
9704690012
84
Valve Cover
9361325012
9361325012
9361325012
85
Valve Fixing Plate
9361324015
9361324015
9361324015
107
Rubber Seat-A (For Comp. )
9351049010
313093081402
9351049010
109
Terminal Cover (For Comp. )
9371511016
313202059600
9371511016
117-3
Hex. Nut w/Sp. Washer
301721180114
301721180114
301721180114
128-1
Rubber (Discharge Pipe)
313155086308
-----
313155086308
(Counter Weight)
-----
-----
-----
173
Capacitor (Start)
9703635014
9703635014
9703635014
178-2
Capillary Holder Rubber
-----
-----
313394274808
187
Clamp No. 1219
313361271706
313361271706
313361271706
210
Main Relay
-----
9353611017
9353611017
218-3
Power Relay
9900074012
-----
-----
233
Power Transformer
-----
9900039011
9900039011
236
Controller PCB Assy
-----
9704299031
9704299055
259
Muffler
-----
-----
313755083903
328
Comp. Plate Assy
9362273060
-----
9362273060
330
Suction Pipe-C
9365136003
-----
-----
330-1
Cond. Inlet Pipe Assy
-----
-----
9371299037
333
Accumulator
313986117201
313986117201
9368391003
334-1
Suction Pipe-B
9365135006
9365411011
-----
334-4
Suction Pipe-D
9365254004
-----
-----
343
Solenoid Coil
-----
9359616108
9359616108
344
4-Way Vaive
-----
9300604017
9300604017
348
Outlet Pipe Assy
9363041019
-----
-----
353
Capillary (Coil)
9365133002
-----
-----
353
Thermistor (Heat-Ex. )
-----
9900043025
9900043025
355
Switch Bracket
313986353607
-----
-----
361
Accumulator Support Assy
-----
-----
313986353804
381
Locking Spacer
-----
313209391403
313209391403
412
Cover Gasket
9371512013
-----
9371512013
420
Capillary Assy
-----
9370686005
9371287027
477
Bellmouth
9359809012
9359809012
9359809012
527
Protection Net (Condenser)
9359845010
9359845010
9359845010
549
Thermostat-Outdoor
935253004
9900037017
9900037017
620
Inlet Pipe (Cond. ) Assy
-----
-----
9365413005
628
Spacer
-----
0600118075
0600118075
629
EMI Filter 2132-1130
-----
0400056119
0400056119
629
EMI Filter 1518-0730
-----
0400056133
0400056133
646
Compressor Cover-B
-----
-----
313986355101
652-1
Thermostat Holder Pipe
-----
313806262805
313806262805
Ref.
No.
Ord.
Q'ty
AOT25ANAL AOT25RZDL
Part No.
AOT25RNAL
AOT25ANAL
AOT25RZDL
AOT25RNAL
58
2003.05.08
