NAME OF PARTS
Remote controller

START/STOP Button

SET TEMP. (Temperature) Button

MODE Button

FAN Button

ECONOMY Button

TIMER MODE (CLOCK AD-
JUST) Button

DAY (DAY OFF) Button

SET BACK Button

SET TIME ( < > ) Button

TIMER DELETE Button

TIMER SET Button

Vertical Airow Direction and
Swing Button
*1

Horizontal Airow Direction and
Swing Button
*2

MAINTENANCE(FILTER RE-
SET) Button
#1

Operation Lamp

Timer and Clock Display

Operation Mode Display

Fan Speed Display

Operation Lock Display

Temperature Display

Function Display
Defrost Display
Thermo Sensor Display
ECONOMY Display
Vertical Swing Display
*3
Filter Display
#1
*
1~3 These functions cannot be used.
(Please also see the operating manual
of the option when using it with options,
etc.)
#
1 Can be used if set correctly during
installation. Please consult authorized
serviceman when using this function.
