Fujitsu ARXG09KLLAP Design & Technical Manual


Wall mounted type
Model: ASYG07KGTB
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
-5.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
0.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
5.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
15.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
20.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
25.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
30.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
35.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
40.0 1.45 0.60 1.64 0.69 1.73 0.79 1.85 0.89 1.98 0.97 2.04 1.12
46.0 0.94 0.25 1.06 0.29 1.12 0.33 1.20 0.37 1.28 0.41 1.32 0.47
Model: ASYG09KGTB
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
-5.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
0.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
5.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
10.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
15.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
20.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
25.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
30.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
35.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
40.0 1.86 0.77 2.10 0.88 2.21 1.01 2.37 1.14 2.53 1.25 2.61 1.43
46.0 1.20 0.32 1.36 0.37 1.43 0.43 1.54 0.48 1.64 0.52 1.69 0.60
Model: ASYG12KGTB
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
-5.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
0.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
5.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
10.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
15.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
20.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
25.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
30.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
35.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
40.0 2.49 1.04 2.82 1.18 2.97 1.36 3.18 1.53 3.40 1.67 3.51 1.92
46.0 1.62 0.44 1.83 0.50 1.93 0.57 2.06 0.64 2.21 0.70 2.27 0.81
Model: ASYG14KGTB
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.92 2.20 4.43 2.51 4.67 2.89 5.00 3.25 5.35 3.55 5.51 4.07
-5.0 3.92 2.20 4.43 2.51 4.67 2.89 5.00 3.25 5.35 3.55 5.51 4.07
0.0 3.92 2.20 4.43 2.51 4.67 2.89 5.00 3.25 5.35 3.55 5.51 4.07
5.0 3.92 2.20 4.43 2.51 4.67 2.89 5.00 3.25 5.35 3.55 5.51 4.07
10.0 3.92 2.20 4.43 2.51 4.67 2.89 5.00 3.25 5.35 3.55 5.51 4.07
15.0 3.92 2.20 4.43 2.51 4.67 2.89 5.00 3.25 5.35 3.55 5.51 4.07
20.0 3.92 2.20 4.43 2.51 4.67 2.89 5.00 3.25 5.35 3.55 5.51 4.07
25.0 3.92 2.20 4.43 2.51 4.67 2.89 5.00 3.25 5.35 3.55 5.51 4.07
30.0 3.92 2.20 4.43 2.51 4.67 2.89 5.00 3.25 5.35 3.55 5.51 4.07
35.0 3.92 2.20 4.43 2.51 4.67 2.89 5.00 3.25 5.35 3.55 5.51 4.07
40.0 2.90 1.21 3.28 1.38 3.46 1.58 3.70 1.78 3.96 1.95 4.08 2.23
46.0 1.88 0.51 2.13 0.58 2.24 0.67 2.40 0.75 2.57 0.82 2.64 0.94
- 494 -
6-2. Cooling capacity
6. Capacity table
OUTDOOR UNIT AOYG36KBTA5
OUTDOOR UNIT
AOYG36KBTA5
