Fujitsu ARXG09KLLAP Design & Technical Manual


Compact cassette type
Model: AUXG07KVLA
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 1.82 1.78 1.74 1.69 1.65
-10.0 -11.0 2.12 2.07 2.02 1.97 1.92
-5.0 -7.0 2.23 2.18 2.13 2.07 2.02
0.0 -2.0 2.56 2.50 2.44 2.38 2.31
5.0 3.0 2.94 2.87 2.80 2.73 2.66
7.0 6.0 2.94 2.87 2.80 2.73 2.66
10.0 8.0 2.94 2.87 2.80 2.73 2.66
15.0 10.0 2.94 2.87 2.80 2.73 2.66
20.0 15.0 2.94 2.87 2.80 2.73 2.66
24.0 18.0 2.94 2.87 2.80 2.73 2.66
Model: AUXG09KVLA
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 2.34 2.29 2.23 2.18 2.12
-10.0 -11.0 2.72 2.66 2.59 2.53 2.46
-5.0 -7.0 2.87 2.80 2.74 2.67 2.60
0.0 -2.0 3.29 3.21 3.13 3.05 2.98
5.0 3.0 3.78 3.69 3.60 3.51 3.42
7.0 6.0 3.78 3.69 3.60 3.51 3.42
10.0 8.0 3.78 3.69 3.60 3.51 3.42
15.0 10.0 3.78 3.69 3.60 3.51 3.42
20.0 15.0 3.78 3.69 3.60 3.51 3.42
24.0 18.0 3.78 3.69 3.60 3.51 3.42
Model: AUXG12KVLA
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 3.12 3.05 2.98 2.90 2.83
-10.0 -11.0 3.63 3.54 3.46 3.37 3.28
-5.0 -7.0 3.83 3.74 3.65 3.56 3.47
0.0 -2.0 4.38 4.28 4.18 4.07 3.97
5.0 3.0 5.04 4.92 4.80 4.68 4.56
7.0 6.0 5.04 4.92 4.80 4.68 4.56
10.0 8.0 5.04 4.92 4.80 4.68 4.56
15.0 10.0 5.04 4.92 4.80 4.68 4.56
20.0 15.0 5.04 4.92 4.80 4.68 4.56
24.0 18.0 5.04 4.92 4.80 4.68 4.56
Model: AUXG14KVLA
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 3.65 3.56 3.47 3.39 3.30
-10.0 -11.0 4.23 4.13 4.03 3.93 3.83
-5.0 -7.0 4.47 4.36 4.26 4.15 4.04
0.0 -2.0 5.12 4.99 4.87 4.75 4.63
5.0 3.0 5.88 5.74 5.60 5.46 5.32
7.0 6.0 5.88 5.74 5.60 5.46 5.32
10.0 8.0 5.88 5.74 5.60 5.46 5.32
15.0 10.0 5.88 5.74 5.60 5.46 5.32
20.0 15.0 5.88 5.74 5.60 5.46 5.32
24.0 18.0 5.88 5.74 5.60 5.46 5.32
Model: AUXG18KVLA
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 4.39 4.29 4.19 4.08 3.98
-10.0 -11.0 5.10 4.98 4.86 4.74 4.62
-5.0 -7.0 5.39 5.26 5.13 5.00 4.87
0.0 -2.0 6.17 6.02 5.87 5.73 5.58
5.0 3.0 7.09 6.92 6.75 6.58 6.41
7.0 6.0 7.09 6.92 6.75 6.58 6.41
10.0 8.0 7.09 6.92 6.75 6.58 6.41
15.0 10.0 7.09 6.92 6.75 6.58 6.41
20.0 15.0 7.09 6.92 6.75 6.58 6.41
24.0 18.0 7.09 6.92 6.75 6.58 6.41
- 512 -
6-3. Heating capacity
6. Capacity table
OUTDOOR UNIT AOYG36KBTA5
OUTDOOR UNIT
AOYG36KBTA5
