1. Compressor frequency control

1-1. Cooling operation

A sensor (room temperature thermistor) built in the indoor unit body will usually perceive difference

or variation between a set temperature and present room temperature, and controls the operation

frequency of the compressor.

• If the room temperature is 6.0 °C higher than a set temperature, the compressor operation fre-

quency will attain to maximum performance.

• If the room temperature is 1.0 °C lower than a set temperature, the compressor will be stopped.

• When the room temperature is within the range of +6.0°C to -1.0°C of the setting temperature, the

compressor frequency is controlled within the range shown in the table below. However, the maxi-

mum frequency is limited in the range shown in the figure below based on the indoor fan mode

and the outdoor temperature.

• Compressor frequency range

Model name Minimum frequency Maximum frequency

ARXG09KLLAP 14 rps 87 rps

ARXG12KLLAP 14 rps 110 rps

ARXG14KLLAP 12 rps 110 rps

ARXG18KLLAP 12 rps 110 rps

1-1. Cooling operation - (01-1) - 1. Compressor frequency control
