INDOOR UNIT

DUCT

ARYG22LMLA

ARYG24LMLA

2012.04.25 57

11 Control Cover A Sub Assy

8 Cabinet L Sub Assy

9 Cabinet R Sub Assy

1 Intake Cover Sub Assy

6 Outlet Panel Sub Assy

4 Evaporator Total Assy

3 Drain Pan Sub Assy

2 Main Panel Sub Assy

7 Intake Frame Assy

Ref. Description Part number

9374516025

9374509010

9374508013

9374512010

9374510016

5 Seal Panel Sub Assy

10 Bracket Pipe Sub Assy

9374515011

9374514014

9374517268

9374513017

9374511013

9374216017
