INDOOR UNIT
DUCT
ARYG22LMLA
ARYG24LMLA
2012.04.25 64
Name and Shape
Q’ty
Use
Hanger
4
For suspending the indoor unit
from ceiling
Drain hose
insulation
1
Insulates the drain hose and
vinyl hose
Cable tie (Large)
1
For fixing drain hose
Cable tie (Small)
1
For remote control and remote
control cable binding
Cable tie
2
For electrical wiring
Wire clamper
1
For electrical wiring
Remote control
1
For air conditioner operation
Remote control cable
1
For connecting the remote
control
Screw (M4 × 16)
2
For installing the remote control
Coupler heat
insulation (Large)
1
For indoor side pipe joint (gas)
Coupler heat
insulation (Small)
1
For indoor side pipe joint
(liquid)
Special nut A (Large flange)
4
For suspending the indoor unit
from ceiling
Special nut B (Small flange)
4
For suspending the indoor unit
from ceiling
