1-2. COOLING OPERATION
1-2-1 COOLING CAPACITY CONTROL
A sensor (room temperature thermistor) built in the indoor unit will usually perceive
difference or variation between a set temperature and present room temperature, and
controls the operation frequency of the compressor.
* If the room temperature is 6.0°C higher than a set temperature,
the compressor operation frequency will attain to maximum performance.
* If the
room temperature is 1.0°C lower than a set temperature, the compressor
will be stopped.
* When the room temperature is between +6.0°C to -1.0°C of the setting temperature,
the compressor frequency is controlled within the range shown in Table1.
However, the maximum frequency is limited in the range shown in Fig.1 based on the
fan speed mode and the outdoor temperature.
minimum
frequency
maximum
frequency
15rps 81rps
ARYG72LHTA
15rps 90rps
ARYG90LHTA
Hi Me Lo Qu
78rps
78rps
59rps
53rps
45rps 43rps
55rps
55rps
53rps
53rps
53rps 45rps
33rps
43rps
43rps
38rps
A zone
B zone
C zone
D-F zone
A zone
B zone
C zone
D-F zone
ARYG72LHTA
( Table 1 : Compressor Frequency Range )
( Fig. 1 : Limit of Maximum Frequency based on Outdoor Temperature )
01-02
84rps
84rps
66rps
55rps
46rps 43rps
60rps
60rps
55rps
55rps
55rps 46rps
33rps
43rps
43rps
38rps
ARYG90LHTA
Fan speed mode
Outdoor air
temperature
A zone
B zone
C zone
D zone
E zone
F zone
When the room
temperature rises
When the room
temperature drops
36°C
32°C
21°C
12°C
2°C
34°C
30°C
19°C
10°C
0°C
