– 81 –
Refrigerant pipe
Distributor
Distributor
ø 15.88mm(5/8")
Refrigerant pipe
ø 9.53mm(3/8")
Capillary tube
Charging valve
Compressor
Dryer
OUTDOOR UNITINDOOR UNIT
Condenser
Evaporator
Evaporator
Refrigerant pipe
ø 15.88mm(5/8")
Refrigerant pipe
ø 9.53mm(3/8")
Cooling
Heating
: Flare coupling
INDOOR UNIT
DryerStrainer
Muffler
Muffler
Charging valve
4-Way
valve
Compressor
Capillary tube
OUTDOOR UNIT
Condenser
Accumulator
Models : AB ✽ 18A / AO ✽ 18AZ
Models : AB ✽ 18R / AO ✽ 18RZ
