Indoor unit type
Type
External connect kit
External input and output
PCB
UTY-XWZX UTY-XWZXZ5 UTY-XWZXZG UTY-XCSXZ2 UTY-XCSX
Compact cassette — — ◌ — ◌
Mini duct — — ◌ — —
Slim duct — — ◌ — —
Medium static pressure duct — — ◌ — —
Wall
mounted
KGTB ◌ — — ◌ —
KGTE ◌ ◌ — ◌ —
KMTB
07-14 model — ◌ — — —
18-24 model — ◌ — ◌ —
KMTE ◌ ◌ — ◌ —
KMCC — ◌ — — —
KMCE ◌ ◌ — ◌ —
KETA — ◌ — ◌ —
KETE ◌ ◌ — ◌ —
Ceiling — — ◌ — ◌
Floor — ◌ — — —
Indoor unit type
Type
KNX converter Network converter
Modbus
converter
UTY-VKSX UTY-VTGX UTY-VTGXV UTY-VMSX
Compact cassette ◌ ◌ ◌ ◌
Mini duct ◌ ◌ ◌ ◌
Slim duct ◌ ◌ ◌ ◌
Medium static pressure duct ◌ ◌ ◌ ◌
Wall
mounted
KGTB ◌
◌*
2
◌*
2
◌
KGTE ◌
◌*
2
◌*
2
◌
KMTB
07-14 model ◌
◌*
1
◌*
1
◌
18-24 model ◌
◌*
2
◌*
2
◌
KMTE ◌
◌*
2
◌*
2
◌
KMCC ◌
◌*
1
◌*
1
◌
KMCE ◌
◌*
2
◌*
2
◌
KETA ◌
◌*
2
◌*
2
◌
KETE ◌
◌*
2
◌*
2
◌
Ceiling ◌ ◌ ◌ ◌
Floor ◌
◌*
3
◌*
3
◌
6-1. Indoor unit - (02-108) - 6. Optional parts
