Fujitsu AS G07KGTB Series Service Manual

Separate wall
Evaporator holder 2 row
32
31
Item no. Part no. Part name Service part
31
9375720254 Evaporator sub assy (For 07 model) ♦
9375720230 Evaporator sub assy (For 09, 12 model) ♦
9375720223 Evaporator sub assy (For 14 model) ♦
9375720247 Evaporator sub assy (For 18 model) ♦
9375720216 Evaporator sub assy (For 22 model) ♦
32
9377764065
Insulation box sub assy (For 07, 09, 12, 14, 18
model)
♦
9377764058 Room thermistor (For 22 model) ♦
3-1. Compact cassette type - (02-7) - 3. Indoor unit parts list
TECHNICAL DATA AND PARTS LIST TECHNICAL DATA AND PARTS LIST
