Power supply
(50 Hz, 230 V)
Indoor rated
Wiring spec. of connection
cable
(Indoor unit to outdoor
unit)
Type Model name
MCA
Input
power
FLA
Cross-
sectional
area
Limited
wiring
length
(A) (W) (A)
(mm
2
)
(m)
Wall mounted
ASYG07KGTB 0.25 23 0.20
1.5 26
ASYG09KGTB 0.30 27 0.24
ASYG12KGTB 0.30 27 0.24
ASYG14KGTB 0.37 33 0.29
ASYG07KGTE 0.25 23 0.20
ASYG09KGTE 0.30 27 0.24
ASYG12KGTE 0.30 27 0.24
ASYG14KGTE 0.37 33 0.29
ASYG07KGTF 0.25 23 0.20
ASYG09KGTF 0.30 27 0.24
ASYG12KGTF 0.30 27 0.24
ASYG14KGTF 0.37 33 0.29
ASYG18KMTB 0.44 38 0.35
ASYG22KMTB 0.49 47 0.39
ASYG24KMTB 0.55 62 0.44
ASYG18KMTE 0.44 38 0.35
ASYG22KMTE 0.49 47 0.39
ASYG24KMTE 0.55 62 0.44
ASYG07KMTB 0.25 23 0.20
ASYG09KMTB 0.30 27 0.24
ASYG12KMTB 0.30 27 0.24
ASYG14KMTB 0.38 33 0.30
ASYG07KMCC 0.25 23 0.20
ASYG09KMCC 0.30 27 0.24
ASYG12KMCC 0.30 27 0.24
ASYG14KMCC 0.38 33 0.30
ASYG07KMCE 0.25 23 0.20
ASYG09KMCE 0.30 27 0.24
ASYG12KMCE 0.30 27 0.24
ASYG14KMCE 0.38 33 0.30
ASYG07KMCF 0.25 23 0.20
ASYG09KMCF 0.30 27 0.24
ASYG12KMCF 0.30 27 0.24
ASYG14KMCF 0.38 33 0.30
- 181 -
10. Electrical characteristics
4-5 UNIT MULTI-SPLIT TYPE 4-5 UNIT MULTI-SPLIT TYPE
