Fujitsu AS G07KGTB Series Design & Technical Manual

Model: ASYG07KETF, ASYG07KETF-B
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 1.54 1.50 1.46 1.43 1.39
-10.0 -11.0 1.91 1.87 1.82 1.78 1.73
-5.0 -7.0 2.27 2.22 2.17 2.11 2.06
0.0 -2.0 2.68 2.61 2.55 2.48 2.42
5.0 3.0 2.94 2.87 2.80 2.73 2.66
7.0 6.0 2.94 2.87 2.80 2.73 2.66
10.0 8.0 2.94 2.87 2.80 2.73 2.66
15.0 10.0 2.94 2.87 2.80 2.73 2.66
20.0 15.0 2.94 2.87 2.80 2.73 2.66
24.0 18.0 2.94 2.87 2.80 2.73 2.66
Model: ASYG09KETF, ASYG09KETF-B
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 1.97 1.93 1.88 1.83 1.79
-10.0 -11.0 2.46 2.40 2.34 2.28 2.22
-5.0 -7.0 2.92 2.86 2.79 2.72 2.65
0.0 -2.0 3.44 3.36 3.28 3.19 3.11
5.0 3.0 3.78 3.69 3.60 3.51 3.42
7.0 6.0 3.78 3.69 3.60 3.51 3.42
10.0 8.0 3.78 3.69 3.60 3.51 3.42
15.0 10.0 3.78 3.69 3.60 3.51 3.42
20.0 15.0 3.78 3.69 3.60 3.51 3.42
24.0 18.0 3.78 3.69 3.60 3.51 3.42
Model: ASYG12KETF, ASYG12KETF-B
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 2.63 2.57 2.51 2.44 2.38
-10.0 -11.0 3.28 3.20 3.12 3.04 2.97
-5.0 -7.0 3.90 3.81 3.71 3.62 3.53
0.0 -2.0 4.59 4.48 4.37 4.26 4.15
5.0 3.0 5.04 4.92 4.80 4.68 4.56
7.0 6.0 5.04 4.92 4.80 4.68 4.56
10.0 8.0 5.04 4.92 4.80 4.68 4.56
15.0 10.0 5.04 4.92 4.80 4.68 4.56
20.0 15.0 5.04 4.92 4.80 4.68 4.56
24.0 18.0 5.04 4.92 4.80 4.68 4.56
Model: ASYG14KETF, ASYG14KETF-B
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 3.07 3.00 2.93 2.85 2.78
-10.0 -11.0 3.82 3.73 3.64 3.55 3.46
-5.0 -7.0 4.55 4.44 4.33 4.22 4.12
0.0 -2.0 5.35 5.22 5.10 4.97 4.84
5.0 3.0 5.88 5.74 5.60 5.46 5.32
7.0 6.0 5.88 5.74 5.60 5.46 5.32
10.0 8.0 5.88 5.74 5.60 5.46 5.32
15.0 10.0 5.88 5.74 5.60 5.46 5.32
20.0 15.0 5.88 5.74 5.60 5.46 5.32
24.0 18.0 5.88 5.74 5.60 5.46 5.32
NOTES:
• TC: Total Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
- 439 -
