Fujitsu AS G07KGTB Series Design & Technical Manual

¢ Indoor unit: 9,000 Btu/h
Cooling
Pipe length
m 2.5 5 10 15 20 25
Height difference H (m)
Indoor unit is higher
than outdoor unit *1
15 — — — 0.956 0.942 0.928
10 — — 0.977 0.963 0.950 0.936
5 — 0.992 0.985 0.971 0.957 0.943
2.5 1.003 0.996 0.989 0.975 0.961 0.947
0 1.007 1.000 0.993 0.979 0.965 0.951
Indoor unit is lower
than outdoor unit *2
-2.5 1.007 1.000 0.993 0.979 0.965 0.951
-5 — 1.000 0.993 0.979 0.965 0.951
-10 — — 0.993 0.979 0.965 0.951
-15 — — — 0.979 0.965 0.951
Heating
Pipe length
m 2.5 5 10 15 20 25
Height difference H (m)
Indoor unit is higher
than outdoor unit *1
15 — — — 0.977 0.958 0.939
10 — — 0.993 0.977 0.958 0.939
5 — 1.000 0.993 0.977 0.958 0.939
2.5 0.993 1.000 0.993 0.977 0.958 0.939
0 0.993 1.000 0.993 0.977 0.958 0.939
Indoor unit is lower
than outdoor unit *2
-2.5 0.991 0.997 0.991 0.975 0.956 0.937
-5 — 0.995 0.988 0.972 0.954 0.934
-10 — — 0.983 0.967 0.949 0.930
-15 — — — 0.962 0.944 0.925
¢ Indoor unit: 12,000 Btu/h
Cooling
Pipe length
m 2.5 5 10 15 20 25
Height difference H (m)
Indoor unit is higher
than outdoor unit *1
15 — — — 0.937 0.912 0.888
10 — — 0.970 0.944 0.919 0.896
5 — 0.992 0.978 0.952 0.927 0.903
2.5 1.010 0.996 0.982 0.956 0.930 0.907
0 1.014 1.000 0.986 0.960 0.934 0.910
Indoor unit is lower
than outdoor unit *2
-2.5 1.014 1.000 0.986 0.960 0.934 0.910
-5 — 1.000 0.986 0.960 0.934 0.910
-10 — — 0.986 0.960 0.934 0.910
-15 — — — 0.960 0.934 0.910
Heating
Pipe length
m 2.5 5 10 15 20 25
Height difference H (m)
Indoor unit is higher
than outdoor unit *1
15 — — — 0.977 0.958 0.938
10 — — 0.993 0.977 0.958 0.938
5 — 1.000 0.993 0.977 0.958 0.938
2.5 0.995 1.000 0.993 0.977 0.958 0.938
0 0.995 1.000 0.993 0.977 0.958 0.938
Indoor unit is lower
than outdoor unit *2
-2.5 0.993 0.997 0.991 0.975 0.956 0.936
-5 — 0.995 0.988 0.972 0.953 0.933
-10 — — 0.983 0.967 0.949 0.929
-15 — — — 0.962 0.944 0.924
- 443 -
7-1. Model: AOYG30KBTA4
7. Capacity compensation rate for pipe length and height difference
OUTDOOR UNIT AOYG30KBTA4 OUTDOOR UNIT AOYG30KBTA4

Fujitsu AS G07KGTB Series Specifications

General

Brand	Fujitsu
Model	AS G07KGTB Series
Category	Air Conditioner
Language	English
