Fujitsu AS G07KGTB Series Design & Technical Manual

¢ Models: ASYG07–14KGTE and ASYG07–14KGTF
Unit: mm
(834)
344 356
327 11332767
62
50
62
84
43
(270)
43
Outline of indoor unit
for pipe inlet Ø65 for pipe inlet Ø65
834 215
3.0
270
373.5
417.5
448
- 50 -
4-5. Wall mounted type
4. Dimensions
4-5 UNIT MULTI-SPLIT TYPE 4-5 UNIT MULTI-SPLIT TYPE
