2. MODEL SELECTION
WALL MOUNTED TYPE6-1-3.
MODEL : AS
 
G07LJCA
Outdoor
temperature
Indoor temperature (°CDB / °CWB)
21.0 / 15.0 23.0 / 16.0 24.0 / 17.0 27.0 / 19.0 29.0 / 21.0 31.0 / 22.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-5.0 1.62 1.26 1.78 1.41 1.92 1.54 2.05 1.66 2.26 1.76 2.46 1.89 2.65 1.99
0.0 1.62 1.26 1.78 1.41 1.92 1.54 2.05 1.66 2.26 1.76 2.46 1.89 2.65 1.99
5.0 1.62 1.26 1.78 1.41 1.92 1.54 2.05 1.66 2.26 1.76 2.46 1.89 2.65 1.99
10.0 1.62 1.26 1.78 1.41 1.92 1.54 2.05 1.66 2.26 1.76 2.46 1.89 2.65 1.99
15.0 1.62 1.26 1.78 1.41 1.92 1.54 2.05 1.66 2.26 1.76 2.46 1.89 2.65 1.99
20.0 1.62 1.26 1.78 1.41 1.92 1.54 2.05 1.66 2.26 1.76 2.46 1.89 2.50 1.95
25.0 1.62 1.26 1.78 1.41 1.92 1.54 2.05 1.66 2.26 1.76 2.38 1.83 2.44 1.89
30.0 1.62 1.26 1.78 1.41 1.92 1.54 2.05 1.66 2.26 1.76 2.30 1.78 2.36 1.85
35.0 1.62 1.26 1.78 1.41 1.92 1.54 2.05 1.66 2.15 1.70 2.23 1.74 2.28 1.82
40.0 1.62 1.26 1.78 1.41 1.87 1.53 1.93 1.60 2.03 1.62 2.11 1.65 2.15 1.74
46.0 1.62 1.26 1.58 1.30 1.75 1.46 1.82 1.56 1.91 1.54 1.98 1.57 2.02 1.65
MODEL : AS
 
G09LJCA
Outdoor
temperature
Indoor temperature (°CDB / °CWB)
21.0 / 15.0 23.0 / 16.0 24.0 / 17.0 27.0 / 19.0 29.0 / 21.0 31.0 / 22.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-5.0 2.09 1.62 2.30 1.82 2.47 1.99 2.64 2.14 2.90 2.27 3.17 2.50 3.42 2.56
0.0 2.09 1.62 2.30 1.82 2.47 1.99 2.64 2.14 2.90 2.27 3.17 2.50 3.42 2.56
5.0 2.09 1.62 2.30 1.82 2.47 1.99 2.64 2.14 2.90 2.27 3.17 2.50 3.42 2.56
10.0 2.09 1.62 2.30 1.82 2.47 1.99 2.64 2 .14 2.90 2.27 3.17 2.50 3.42 2.56
15.0 2.09 1.62 2.30 1.82 2.47 1.99 2.64 2 .14 2.90 2.27 3.17 2.50 3.42 2.56
20.0 2.09 1.62 2.30 1.82 2.47 1.99 2.64 2 .14 2.90 2.27 3.17 2.50 3.22 2.51
25.0 2.09 1.62 2.30 1.82 2.47 1.99 2.64 2 .14 2.90 2.27 3.06 2.42 3.14 2.43
30.0 2.09 1.62 2.30 1.82 2.47 1.99 2.64 2 .14 2.90 2.27 2.96 2.35 3.04 2.38
35.0 2.09 1.62 2.30 1.82 2.47 1.99 2.64 2 .14 2.77 2.19 2.88 2.30 2.93 2.35
40.0 2.09 1.62 2.30 1.82 2.40 1.97 2.49 2.07 2.61 2.09 2.71 2.18 2.77 2.24
46.0 2.09 1.62 2.04 1.68 2.26 1.88 2.34 2.01 2.46 1.98 2.55 2.07 2.60 2.13
MODEL : AS
 
G12LJCA
Outdoor
temperature
Indoor temperature (°CDB / °CWB)
21.0 / 15.0 23.0 / 16.0 24.0 / 17.0 27.0 / 19.0 29.0 / 21.0 31.0 / 22.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-5.0 2.78 1.96 3.06 2.26 3.29 2.50 3.52 2.68 3.87 2.90 4.22 3.04 4.42 3.14
0.0 2.78 1.96 3.06 2.26 3.29 2.50 3.52 2.68 3.87 2.90 4.22 3.04 4.42 3.14
5.0 2.78 1.96 3.06 2.26 3.29 2.50 3.52 2.68 3.87 2.90 4.22 3.04 4.42 3.14
10.0 2.78 1.96 3.06 2.26 3.29 2.50 3.52 2.68 3.87 2.90 4.22 3.04 4.42 3.14
15.0 2.78 1.96 3.06 2.26 3.29 2.50 3.52 2.68 3.87 2.90 4.22 3.04 4.42 3.14
20.0 2.78 1.96 3.06 2.26 3.29 2.50 3.52 2.68 3.87 2.90 4.22 3.04 4.29 3.18
25.0 2.78 1.96 3.06 2.26 3.29 2.50 3.52 2.68 3.87 2.90 4.08 2.94 4.19 3.08
30.0 2.78 1.96 3.06 2.26 3.29 2.50 3.52 2.68 3.87 2.90 3.94 2.86 4.05 3.02
35.0 2.78 1.96 3.06 2.26 3.29 2.50 3.52 2.68 3.70 2.81 3.84 2.80 3.91 2.97
40.0 2.78 1.96 3.06 2.26 3.20 2.48 3.32 2.59 3.49 2.68 3.62 2.66 3.69 2.84
46.0 2.78 1.96 2.72 2.08 3.01 2.38 3.12 2.53 3.28 2.54 3.40 2.52 3.47 2.71
COOLING CAPACITY
TC : Total Capacity kW.
SHC : Sensible Heat Capacity kW.
The data is based on the following conditions.
Pipe length : 5m [Outdoor unit - Branch box], 3m [Branch box - Indoor unit]
Height difference : 0m [Outdoor unit - Indoor unit].
- (02 - 22) -
MODEL SELECTION MODEL SELECTION
