4
Fig. 1 Indoor Unit
1 Operating Control Panel (Fig. 2)
2 MANUAL AUTO button
3 Remote Control Signal Receiver
4 Indicator Lamps (Fig. 3)
5 OPERATION Indicator Lamp
(green ...... COOL, DRY, FAN)
(red .......... *HEAT)
6 TIMER Indicator Lamp (yellow)
7 SWING Indicator Lamp (orange)
(VERTICAL SWING)
8 SWING Indicator Lamp (orange)
(HORIZONTAL SWING)
● If the TIMER indicator lamp flashes when
the timer is operating, it indicates that a
fault has occurred with the timer setting
(See page 15 Auto Restart).
9 Intake Filter (Fig. 4)
; UP/DOWN Air Direction Flaps
A RIGHT/LEFT Air Direction Louvers
(behind UP/DOWN Air Direction Flaps)
B Drain Hose
C Air Cleaning Filter (optional)
Fig. 5 Outdoor Unit
D Intake Port
E Outlet Port
F Pipe Unit
Fig. 6 Remote Control Unit
G SLEEP button
H MASTER CONTROL button
I SET TEMP./SET TIME buttons ( )
J Signal Transmitter
K TIMER button
L FAN CONTROL button
M START/STOP button
N AIR FLOW DIRECTION
VERTICAL SET button
O AIR FLOW DIRECTION
VERTICAL SWING button
P AIR FLOW DIRECTION
HORIZONTAL SET button
Q AIR FLOW DIRECTION
HORIZONTAL SWING button
Rear side (Fig. 7)
R TIME ADJUST button
S ACL button
(located inside battery compartment)
T TEST RUN button
● This button is used when installing the air
conditioner and should not be used under
normal conditions as it will cause the air
conditioner’s thermostat function to oper-
ate incorrectly.
● If this button is pressed during normal op-
eration, the unit will switch to test opera-
tion mode, and the indoor unit’s OPERA-
TION indicator lamp and TIMER indicator
lamp will begin to flash simultaneously.
● To stop the test operation mode, either
press the TEST RUN button once again, or
press the START/STOP button to stop the
air conditioner.
U Remote Control Unit Display (Fig. 8)
V Transmit Indicator
W Clock Display
X Operating Mode Display
Y Timer Mode Display
Z Fan Speed Display
[ Temperature Set Display
\ Timer Set Indicator
] Temperature Set Indicator
