Fujitsu ASU12RLF Service Manual

412011.01.12
OUTDOOR UNIT
Connector : BLACK
GREEN
BLUE
RED
YELLOW
65
73
74
63
64
66
69
70
68
67
71
61
72
62
79
78
77
76
75
63 Inverter Box C
64 Inverter Box Duct
65 Inverter Box Cover
66 Heat Sink A
67 Inverter Box D
68 Terminal (3P)
69 Terminal (6P)
71 Terminal (3P)
72 ACTPM
73 Power Supply PCB Assy
9375140014
9374609017
9375139018
9375138011
9374606047
9900203016
70 Terminal (3P) 9306489045
9900016036
9900433017
9703457012
9705647183
74 Controller PCB Assy
75 Heat Sink Thermistor
76 Compressor Thermistor
77 Thermistor (Outdoor)
78 Heat Exchanger Thermistor
79 Discharge Thermistor
9708013367
9900311018
9900156053
9900477011
9900540005
9900621018
61 Inverter Box A
62 Inverter Box B Assy
9374603015
9374625048
Ref. Description Part number
