45
2010.06.29
INDOOR UNIT
COMPACT WALL MOUNTED
ASU7RLF
ASU9RLF
ASU12RLF
51
52 Box Shield
Control Box
53
Terminal
Earth Terminal
54
55 Controller PCB Assy (7)
55 Controller PCB Assy (9)
55 Controller PCB Assy (12)
56
Control Cover
Parts number
DescriptionRef
9318187014
9317575010
9317659024
9317923002
9708536019
9317662000
57
Cover Shield
58
59
Display Case
Display PCB Assy 9707649024
9900529017
9316586017
9708536026
9708536033
51
53
54
55
56
57
58
59
52
