Fujitsu ASU12RLF Service Manual

522010.06.30
38
37
34
35
39
32
36
31
33
INDOOR UNIT
COMPACT CASSETTE
AUU9RLF
AUU12RLF
AUU18RLF
31 Cabinet A Assy 9375492014
32 Cabinet B 9375494018
37 Bell Mouse 9375503017
38 Drain Pan Sub Assy 9377765024
33 Wire Cover 9375516017
34 Pipe Cover 9375515027
35 Hook R 9375504014
36 Hook L 9375505011
39 Drain Cap 9375502010
Ref. Description Part number
