Fujitsu ASU12RLF1 - Page 103

8. Valve Cover sub assy removal
Remove the 3 mounting screws.
Remove the Valve Cover sub assy.
9. Thermo Holder removal
Remove the 1 mounting screw.
Remove the Thermo Holder by sliding upward.
03-23
Valve Cover sub assy
Hook
Thermo Holder
