- (01 - 08) -
WALL MOUNTED TYPE
ASU9-15RLS3
WALL MOUNTED TYPE
ASU9-15RLS3
INSTALLATION PLACE
Unit : in. (mm)
2(50)
5(127)
2(50)
6(133)
60(1,500)
2(50)
or more
or more
4(84)
71(1,800)
