Fujitsu ASU12RLS3 Design & Technical Manual

- (02 - 14) -
OUTDOOR UNIT AOU9-15RLS3H OUTDOOR UNIT AOU9-15RLS3H
ELECTRIC CHARACTERISTICS9.
Model name AOU9RLS3H AOU12RLS3H AOU15RLS3H
Power supply
Voltage V 208 / 230 ~
Frequency Hz 60
MCA A
14.4
18.2
Starting Current A 3.3 4.7 5.2
Wiring Spec. *
1
MAX. CKT. BKR A 15
20
Power Cable AWG 14 12
Connection cable
*2
AWG 14
Limited wiring length : ft. (m) 68 (21)
*1: Selected sample based on Japan Electrotechnical Standards and Codes Committee E0005.
*2: Limit voltage drop to less than 2%. Increase conductor size if voltage drop is 2% or more.
MCA : Min Circuit Amp (Calculation based on UL1995)
MAX. CKT. BKR : Maximum Circuit Breaker

Fujitsu ASU12RLS3 Specifications

General

Cooling Capacity	12, 000 BTU/h
Refrigerant	R410A
Weight (Indoor Unit)	20 lbs
Type	Mini-Split
Noise Level (Indoor Unit)	22 dB(A)
