Fujitsu ASU12RLS3

OUTDOOR UNIT
2014.12.19 17
32 Compressor Assy 9317117005
34 3-way Valve Sub Assy 9317109000
37 Pulse Motor Valve Assy 9332368048
4-way Valve Assy 9315311092
36 Solenoid 9970110047
31 Condenser Total Assy 9317089135
38 Expansion Valve Coil 9970095030
35
33 2-way Valve Assy 9332371000
Ref. Description Part number
32
31
33
37
34
38
35
36
