OUTDOOR UNIT
24
23
27
25
26
32
30
31
21
22
28
29
29 Condenser Assy (9R2)
29 Condenser Assy (12R2)
9314220012
9314186011
26 Solenoid 9970048012
30 Compressor Assy (9R2)
30 Compressor Assy (12R2)
9314228018
9314200014
32 Noise Insulation B 9314530012
25 4-way Valve Assy 9314194016
27 Capillary Assy (9R2)
27 Capillary Assy (12R2)
9314225017
9314192012
23 2-way Valve Assy 9314554018
24 3-way Valve Assy 9314022012
22 Bracket Valve 9331649001
28 Heat Exchanger Thermistor 9900307011
31 Noise Insulation A 9314417023
21 Bracket Valve Cover 9331683005
Ref. Description Part number
