OUTDOOR UNIT
50
48
47
49
46
45
44
42
41
43
50 Cover Terminal C 9313939014
42 Control Cover 9313936013
43 PCB Assy (9R2)
43 PCB Assy (12R2)
9705717015
9705717022
45 Capacitor Plastic 9307588167
44 Relay 9900262013
49 Bracket Conduit 9313938017
47 Terminal 9703874031
46 Capacitor Clamp 313468061808
41 Control Box Assy 9314293016
48 Bracket Terminal 9313937010
Ref. Description Part number
