60%
70%
80%
90%
100%
110%
120%
130%
140%
150%
Capacity(%)
14 32 50 68 86 104
30%
40%
50%
60%
70%
80%
90%
100%
110%
120%
Input(%)
14 32 50 68 86 104
115
66
66
115
<Capacity>
<Input>
Cooling
Indoor:80/65
Indoor:80/65
Outdoor DB( F)
Outdoor DB( F)
Both capacity and input change largely when temperature is 50 or less degrees F, as outdoor fan speed
is decreased due to low ambient temperature cooling control.
Both capacity and input change more largely at less than 32 degrees F of ambient temperature as
outdoor fan speed is decreased further.
*
*
Both capacity and input decrease when temperature is 66 or less degrees F, for compressor
frequency restrictions operate.
Both capacity and input decrease when temperature is 104 or more degrees F, as compressor speed is
decreased due to current release protection.
*
*
